Gold Concentrator
Contact Now
Products Details
Description
Gold concentrator applies recoil pressure water to the inner surface of the beneficiation component while using the beneficiation principle of the traditional beneficiation centrifuge.
Features
1)Efficient recovery rate: When the recovery rate of gold concentrator reaches over 90%.
2)Technical improvement: the extraction rate of placer gold with 200 meshes or more is 96%, and the service life is increased by three times.
3) Reasonable structure: the equipment has reasonable structure, simple installation, small floor space, simple operation, stable mineral processing, clear ore separation, large capacity and high efficiency.
4) Material characteristics: made of special PVC plastic, with light weight, moisture-proof, rust-proof and corrosion resistance.
Advantages
1. High efficiency: The gold concentrator adopts advanced wind separation technology, which can quickly and accurately separate the gold components in gold ore.
2. Energy-saving and environmental protection: the noise and dust pollution generated by this equipment during operation are less, which meets the environmental protection requirements of modern mine production.
3. Simple operation: The structure design of the gold concentrator is reasonable, and the operation is simple and convenient.
4. Wide application range: the equipment is not only suitable for large gold mines, but also suitable for small and scattered gold mines.
Working Principle
During the working process, the pulp enters the mineral processing parts through the central ore feeding pipe, and under the centrifugal force of high-speed rotation, the pulp moves upward along the cone. Light minerals are discharged from the upper periphery of the cone under the action of centrifugal force, while heavy minerals are kept loose under the interaction of fluidized water and interference settlement, and finally deposited between grooves and enriched, by adjusting the pressure of backwashing water (0.03-0.06Mpa), minerals with different densities can be effectively separated.
Application
Gold concentrator is mainly used to extract monomer gold from placer gold, vein gold and polymetallic ore, especially suitable for gold prospecting and rock gold equipment in dry land or river course.
Technical Parameters
Model | Capacity (TPH) | Feed Size (mm) | Water Consumption (m³/h) | Power (kW) | Weight (kg) | Dimensions (L x W x H, mm) | Application |
GC-10 | 0.5-1.0 | 2 | 1-2 | 1.1 | 100 | 1,000 x 500 x 600 | Small-scale gold concentration |
GC-20 | 1.0-2.0 | 3 | 2-3 | 1.5 | 150 | 1,200 x 600 x 700 | Medium-scale gold processing |
GC-30 | 2.0-3.0 | 4 | 3-4 | 2.2 | 200 | 1,500 x 700 x 800 | Large-scale gold concentration |
GC-50 | 3.0-5.0 | 5 | 4-5 | 3.0 | 300 | 1,800 x 800 x 900 | Industrial gold processing |
GC-100 | 5.0-10.0 | 6 | 5-10 | 5.5 | 500 | 2,000 x 1,000 x 1,000 | Heavy-duty gold mining |
