Apron Feeder
Contact Now
Products Details



Description
Apron feeder is a robust, heavy-duty conveyor designed to handle large, heavy, and abrasive materials. It consists of overlapping metal plates mounted on chains, driven by a motor to move materials from a hopper to downstream equipment like crushers or screens.
Features
1)Heavy-Duty Design: Built to handle large, heavy, and abrasive materials.
2)Durable Construction: Made with wear-resistant plates and chains for long-lasting performance.
3)Controlled Material Flow: Ensures steady and reliable feeding to downstream equipment.
4)Wide Applications: Ideal for mining, cement, and metallurgy industries.

Advantages
1.High durability: made of wear-resistant materials, suitable for handling heavy and abrasive materials.
2.Uniform feeding: ensure that materials are continuously and evenly conveyed to downstream equipment.
3.Strong adaptability: suitable for large, heavy and abrasive materials.
4.Convenient maintenance: simple structure and easy maintenance and repair.
Working Principle
Apron feeder operates by using a series of overlapping metal plates (aprons) mounted on heavy-duty chains. These chains are driven by sprockets connected to a motor, which moves the plates forward. As the plates move, they carry large, heavy, or abrasive materials from a hopper or storage bin to downstream equipment, such as crushers or screens. The apron feeder ensures a continuous and controlled flow of materials, making it ideal for handling tough and bulky loads in industries like mining, cement, and metallurgy.
Application
Apron feeder is used in mining industry, cement industry, metallurgy industry, chemical industry and so on.

Technical Parameters
Model | Capacity (TPH) | Feed Size (mm) | Power (kW) | Chain Speed (m/s) | Weight (kg) | Application |
AF-1000 | 500-800 | 600 | 15 | 0.05-0.15 | 10,000 | Mining and heavy-duty material handling |
AF-1500 | 800-1200 | 800 | 22 | 0.05-0.15 | 15,000 | Large-scale mining operations |
AF-2000 | 1200-1500 | 1000 | 30 | 0.05-0.15 | 20,000 | Cement and aggregate production |
AF-2500 | 1500-2000 | 1200 | 45 | 0.05-0.15 | 25,000 | Industrial bulk material handling |
AF-3000 | 2000-2500 | 1500 | 55 | 0.05-0.15 | 30,000 | Heavy-duty mining and quarrying |
